Professional and dedicated industrial paint manufacturer
This series of products has excellent acid and alkali resistance and reflectivity. The sintered color is stable, the adhesion is strong after sintering, and the surface is smooth.
Eco-friendly water-based solar glass enamel
Application scope: suitable for printing tempered glass such as solar glass.
Product characteristics: white gelatinous body, black gelatinous body.
Features: this series of products has excellent acid and alkali resistance and reflectivity. The sintered color is stable, the adhesion is strong after sintering, and the surface is smooth.
Product model and description:
MY501-856 | Environmentally friendly solar white enamel with a reflectivity more than 83, passed PID test. |
MY871-58-701G | Environmentally friendly solar black enamel with a reflectivity more than 4, passed PID test. |
Parameter of MY501-856:
Items | Results | Conditions |
Color | white | RAL9003 |
Solid Content | 80%±2% | |
Enamel Fineness | ≤10μm | Scraper fineness meter |
Screen Printing Mesh | 150-250 mesh | |
Screen Printing Temperature/ Humidity | 22±5°C/50±10% | |
Sintering Condition | 680-720°C | |
Enamel Viscosity | >18000mPa.s/25°C | Digital viscometer |
Resistivity | 1.86*10^14Ω.m | Resistance tester |
Recommended Dilution Ratio | 2%-4% | |
Expansion Coefficient | 75~86*10-7/°C | Coefficient of expansion meter |
Adhesion | ≥15N | Elcometer 3092 Hardness tester |
Enamel Thickness | 20-26μm | Micrometer |
Enamel Adhesion | Grade 0 | Cross-Cut Tester |
Enamel Reflectivity | 82%±1% | Spectrophotometer 380nm-1100nm |
Falling Ball Test | ≥0.9m | 227g impact non-silksreen intersection |
PID96 | No discoloration | -1500V, 85%RH, 85°C, 96h |
PCT96 | Adhesion class 0, ΔR≤1% | 121°C, 100%RH, 96h |
Peel Strength With Adhesive Film | ≥70N/cm After aging test≥40N/cm | Tensile testing machine |
Bending Strength | ≥ 100MPa | Bending testing machine (screen printing side up) |
Shelf Life (Dry at Room Temperature / Month) | 12 |
