Professional and dedicated industrial paint manufacturer
Possessing excellent chemical resistance, the decorated glass is more durable and long-lasting.
① Application scope: 18 basic colors, suitable for colored enamelled tempered architectural glass, with excellent acid and alkali resistance.
② Product Characteristics: powder form, printing enamel slurry, water-soluble printing enamel slurry, water-soluble roller coating slurry.
③ Features: Possessing excellent chemical resistance, the decorated glass is more durable and long-lasting.
④ Sintering temperature: 620 - 720℃ (1148 -1328℉).
1. Parameter
Application | Screen printing | Roller printing | |
Enamel model | Oiled infrared | Water-friendly infrared | Water-friendly infrared |
Recommended medium | 63-485 | 733-63 | 733-63 |
Recommended diluent | RM362 | RM444 | RM444 |
Powder to oil ratio | 5:1 | 5:1 | 4.2:1 |
Viscosity | 15-20Pa.s | 15-20Pa.s | 15-20Pa.s |
Printing temperature | 15-25℃ | 15-25℃ | 15-25℃ |
Humidity | 30-60% | 30-60% | 30-60% |
Printing mesh | 43-100T | 43-100T | |
Thickness | 20-40um | 20-40um | 80-120um |
Dry temperature | 100-150℃ | 100-150℃ | 100-150℃ |
Storage temperature | 5-25℃ | 5-25℃ | 5-25℃ |
Shelf life | 12 months | 12 months | 12 months |
2. Color:
Basic color | Oil-based | Water-based |
WHITE | AF2000-63-485 | AF2000-733-63 |
SIGNAL WHITE | AF2001-63-485 | AF2001-733-63 |
LEMON YELLOW | AF2100-63-485 | AF2100-733-63 |
CITRUS YELLOW | AF2200-63-485 | AF2200-733-63 |
HONEY YELLOW | AF2202-63-485 | AF2202-733-63 |
IRON RED | AF2300-63-485 | AF2300-733-63 |
GREEN | AF2400-63-485 | AF2400-733-63 |
TURQUOISE | AF2401-63-485 | AF2401-733-63 |
CHROME GREEN | AF2402-63-485 | AF2402-733-63 |
BLUE | AF2500-63-485 | AF2500-733-63 |
BLACK | AF2600-63-485 | AF2600-733-63 |
AUTUMN BROWN | AF2700-63-485 | AF2700-733-63 |
RUST BROWN | AF2730-63-485 | AF2730-733-63 |
CHOCOLATE BROWN | AF2740-63-485 | AF2740-733-63 |
IMITATION ETCH | AF2900-63-485 | AF2900-733-63 |
YELLOW | AF2201-63-485 | AF2201-733-63 |
FLAMING RED | AF2301-63-485 | AF2301-733-63 |
DUTCH ORANGE | AF2302-63-485 | AF2302-733-63 |
EXTRA BLACK | AF2601-63-485 | AF2601-733-63 |
WHITE | YB61001-3 | YB61001-6 |
BLACK | YB62010-3 | YB62010-6 |
MEDIUM | RM362 | RM444 |
3. Test:
1. Acid resistance test results:
l 3.7% HCI, tested at an indoor temperature of 15 minutes, according to ASTM C 724-91 standard, results in grades 2-3.
l 10% citric acid, tested at room temperature for 15 minutes, according to ASTM C 724-91 standard, results in grades 1-2.
l 4% acetic acid, tested at room temperature for 24 hours according to ASTM C 724-91 standard, results in grades 2-3.
2. Alkali proof test results: 10% NaOH, tested at 95 ℃ for 2 hours, according to ASTM C1203-91 standard, the result is<1.0mg/cm2.
